N1 Frame Black

N1 Frame Black
N1 Frame Black
N1 Frame Black
N1 Frame Black
N1 Frame Black
N1 Frame Black
Factory stock
N1 Frame Black
N1 Frame Black
N1 Frame Black
N1 Frame Black
N1 Frame Black
N1 Frame Black

N1 Frame Black
  • Availability: In stock
  • Model: N1FRB
  • Weight: 100.00kg
  • Dimensions: 185.00cm x 65.00cm x 65.00cm
Product Views: 8279
Ex Tax: 999.17€

Available Options


Lastest 2016 product from the RSeat development team, the N1 is a new generation simulator built, like its little brother the RS1, with a modular design. Everything has been reviewed, including ergonomics, strength, comfort and upgradeability. The N1 will be your partner for long sessions of racing, whether you are a professional or an experienced enthusiast. This is the perfect chassis for you!

Support :

Specifications :

  • NEW! Pedals with sliders for easy adjustment
  • Support PC, PS3, PS4, PS5, XBOX 360, XBOX One, XBOX Series X | S (check what's supported tab below)
  • Applicable for users from 127cm (4’2″) up to 200cm+ (6’67″+)
  • Seat carry weight up to 140kg (308 lbs)
  • Seating position Rally/GT
  • Modular Frame (You can upgrade with accessories)
  • Seat Sliders Included
  • Footprint dimensions: L x W x H 1815 x 640 mm. x 755 mm. (71.45” x 25.2” x 29.7”)
  • 2 year Warranty on all RSeat Manufactured components including chassis and seat
  • 100% Made in EU: Engineered, Designed and Manufactured in Europe.

Chassis :

  • Frame step on the ground by 8 adjustable legs (37mm diameter each).
  • Casters Ready (M8 Thread)
  • Made of Mandrel Bend carbon steel tubes NPS 1-1/2 (Din 48.3mm)
  • Total height (without the seat): 755 mm (29.7”)
  • Total width: Rear: 640 mm (25.2”)
  • Length: 1815 mm. (71.45”)
  • Pedal plate width 364 mm. (13.62”)
  • Pedal plate adjust from full flat up to 60°
  • Wheel mounting plate allow to adjust height of the wheel ±120 mm (4.72”)
  • Slide pedals front-backwards with sliders (rails) ±120mm (4.72inch)
  • Slide The seat front-backwards with sliders (rails) ±120mm (4.72inch)
  • Ready for upgrades

Adjustability :

Available Upgrades (check Accessories tab below) :

  • 1. Buttkicker mounting kit. Support Buttkicker ™ Gamer 2, Pearl ™ THMP1, ButtKicker ™ Simulation Kit, Earthquakesound® ShellShoxx and more..
  • 2. Tablet and Buttonbox mounting kit. All way adjustable including tilt and angle.
  • 3. Keyboard and mouse tray. All way adjustable including angle, tilt and height, user is able to place the keyboard and mouse tray in front of the wheel.
  • 4. Speakers Mounting kit. Logitech Z906 Supported and more..
  • 5. Shifter and Handbrake Upgrade kit. Support Thrustmaster TH8RS, TH8A Add-On Shifter, TSS Handbrake Sparco Mod – Fanatec ClubSport Shifter SQ (all versions), ClubSport Shifter, ClubSport Handbrake – Logitech G29 Shifter, G920 Shifter, G27 Shifter, G25 Shifter.
  • Additional upgrades include D-BOX Motion, TV/monitor stands for up to 3x47inch tv's.

What's Included :

  • Chassis body (including seat sliders and pedal plate sliders)
  • Pedals Support
  • Wheel Support
  • Seat L mounts
  • Assembly instruction with tools and screws included to attach you wheel, pedals and shifter
  • Carton box and bubble wrap protection inside the box to prevent damages on transit. N.W 100kg

Packaging dimensions :

Box 1 Dimensions: L x W x H 185 x 65 x H30cm (72.84" x 25.6" x 11.8" ) G.W 70kg (154lbs)

Box 2 Dimensions: L x W x H 97 x 64 x H48cm (38.2" x 25.2" x 18.9" ) G.W 25kg (66lbs)

What's in the box :

Support :

  • We provide on site support through ticket or live-chat.
  • Distributor network allow to have full support in your area.

Shipping information :

Warning: Shipping of this product is not possible by DHL , the length of 185cm and weight of 100kgs exceeds the standards for this shipping company.
